ATEN
ATEN CL5716MUKIT 16-port 17" LCD KVM switch
16-port 17-inch LCD KVM console kit controls up to sixteen computers from a single rack-mounted display with included USB and PS/2 cables
- TypeUSB, PS/2
- Computer Connections16 Ports
- Monitor Connections1 Port
- Video Resolution75Hz
- PC SelectionHotkeys, OSD
- FeaturesSpace saving technology-up to two consoles (one bus) control
- Control 16 computers from a single 17" LCD console
- Save rack space with integrated keyboard, monitor and KVM in 1U
- Switch instantly between servers using hotkeys or on-screen display
- Connect both USB and PS/2 systems with included cable kits
- Manage the KVM locally or from a remote external console
16-Port LCD KVM Console Kit
The ATEN CL5716MUKIT combines a 17-inch LCD panel with a 16-port KVM switch in a single rack-mountable unit. It enables administrators to manage up to sixteen servers from one integrated keyboard, monitor and mouse console. The kit ships new with all required USB and PS/2 connection cables included.
Single-Bus Control with Dual-Interface Support
One bus controls the entire sixteen-computer stack, freeing rack space that separate consoles would occupy. The switch accepts both USB and PS/2 peripherals on the server side, so legacy and current hardware can coexist without adapters. An extra console port allows a second external keyboard, monitor and mouse to manage the same systems remotely.
Suited for Dense Server Racks
This unit fits environments where seventeen-inch rack depth and a single local console are acceptable. Operators who need simultaneous multi-user access, higher video refresh rates or a larger display diagonal should evaluate alternative KVM architectures.
Highlights
- Control 16 computers from a single 17" LCD console
- Save rack space with integrated keyboard, monitor and KVM in 1U
- Switch instantly between servers using hotkeys or on-screen display
- Connect both USB and PS/2 systems with included cable kits
- Manage the KVM locally or from a remote external console
Specifications
| Brand | ATEN |
|---|---|
| Model | CL5716MUKIT |
| Type | USB, PS/2 |
| Computer Connections | 16 Ports |
| Monitor Connections | 1 Port |
| Video Resolution | 75Hz |
| PC Selection | Hotkeys, OSD |
| Features | Space saving technology-up to two consoles (one bus) control up to 8/16 computers Extra console port-manage computers in the LCD KVM switch from an external console Dual interface-supports PS/2 and USB keyboards and mice in the KVM Ports Supports external USB mouse USB peripheral support for attached computers Convenient station and port selectors, each with two 7-segment LED displays Dedicated Hotkey Mode and OSD Invocation Keys Convenient computer selection via mouse-driven OSD Console lock- locks the console draw to remain securely locked away when not in use Daisy chain up to 31 |
| Weight | 50 |
| Package Contents | 1 x CL5716 KVMP Switch with standard Rack Mounting Kit 4 x 2L5201U 8 x 2L5202U 4 x 2L5203U 1x 5-in-1 console cable 1x Firmware Upgrade Cable 1x Power Cord 1x Grounding Wire 1x User Manual 1x Quick Start Guide |
| Shipping weight | 45.36 kg |
| Package size | 914 × 914 × 23 mm |
Questions about this item
How many computers can the CL5716MUKIT control simultaneously?
The CL5716MUKIT supports up to 16 computer connections through its 16-port KVM switch, allowing a single console to manage all connected systems.
What is the screen refresh rate of the built-in 17" LCD panel?
The integrated 17-inch LCD operates at a 75Hz video resolution, providing stable display output for the connected servers.
Which cable sets are included for the USB and PS/2 server connections?
The kit includes four 2L5201U, eight 2L5202U, and four 2L5203U cables plus a 5-in-1 console cable for immediate deployment.
