ATEN CL5708M 17" LCD 8-Port PS/2 USB KVM Switch
A 1U rack-mountable sliding console with a 17" LCD, keyboard and touchpad controls up to 8 computers via PS/2 or USB and can be daisy-chained to manage 256 systems
- TypeUSB, PS/2
- Console ConnectorsKeyboard, Mouse, and Monitor 1 x SPHD-18 Male (Yellow) Monit
- Computer Connections8 Ports
- Monitor Connections1 Port
- Video Resolution1280 x 1024 @ 75 Hz
- PC SelectionPush Buttons/Hot Keys/OSD
- 17" LCD and keyboard fit in 1U rack space saving server room area
- Eight computers controlled from one console reducing hardware clutter
- Daisy-chain up to 31 extra switches managing 256 systems total
- Auto-scan cycles every 1 to 255 seconds for hands-free monitoring
- Dual PS/2 and USB support connects legacy and modern servers
Control Unit for Eight Computers
The ATEN CL5708M is a 1U rack-mountable KVM switch with an integrated 17-inch LCD, keyboard and touchpad. It lets a single operator manage up to eight computers directly, and up to 256 computers when 31 additional switches are daisy-chained. The sliding housing saves rack space while keeping the console accessible.
Suits Single-Console Server Rooms.
This switch fits administrators who need one local console to control a rack of mixed PS/2 and USB servers. It does not suit environments where several technicians must work on different machines at the same time, because only one active console bus is provided. Buyers who require simultaneous independent access should consider a multi-user KVM solution instead.
Maximum Video Resolution Is 1280 x 1024 at 75 Hz
The integrated panel and video path support 1280 x 1024 at 75 Hz. If the connected servers output higher resolutions, the image will be scaled or may not display correctly. Verify that every target system can run at or below this resolution before deployment.
Highlights
- 17" LCD and keyboard fit in 1U rack space saving server room area
- Eight computers controlled from one console reducing hardware clutter
- Daisy-chain up to 31 extra switches managing 256 systems total
- Auto-scan cycles every 1 to 255 seconds for hands-free monitoring
- Dual PS/2 and USB support connects legacy and modern servers
Specifications
| Brand | ATEN |
|---|---|
| Model | CL5708M |
| Type | USB, PS/2 |
| Console Connectors | Keyboard, Mouse, and Monitor 1 x SPHD-18 Male (Yellow) Monitor 1 x USB Type-A Female (White) Flash ROM Upgrade 1 x RJ-11 Female |
| Computer Connections | 8 Ports |
| Monitor Connections | 1 Port |
| Video Resolution | 1280 x 1024 @ 75 Hz |
| PC Selection | Push Buttons/Hot Keys/OSD |
| AutoScan Interval | 1-255 sec. |
| Temperature | Storage -4~140F (-20~60C) Operation 32~122 F(0~50 C) |
| Power Features | 100-240 V AC, 1 A 120V, 27.5W/230V, 23W |
| Features | Space saving technology-up to two consoles (one bus) control up to 8/16 computers Extra console port-manage computers in the LCD KVM switch from an external console Dual interface-supports PS/2 and USB keyboards and mice in the KVM Ports Supports external USB mouse USB peripheral support for attached computers Convenient station and port selectors, each with two 7-segment LED displays Dedicated Hotkey Mode and OSD Invocation Keys Convenient computer selection via mouse-driven OSD Console lock- locks the console draw to remain securely locked away when not in use Daisy chain up to 31 |
| Dimensions | 18.9" x 1.7" x 24.9" |
| Weight | 30.3 lbs. |
| Shipping weight | 17.55 kg |
| Package size | 714 × 673 × 145 mm |
