ASUS
ASUS TUF-RTX4070TI-12G-GAMING graphics card
Refurbished GeForce RTX 4070 Ti with 12GB GDDR6X, 7680 CUDA cores, triple axial-tech fans, military-grade capacitors and a metal exoskeleton
- InterfacePCI Express 4.0
- Chipset ManufacturerNVIDIA
- GPU SeriesNVIDIA GeForce RTX 40 Series
- GPUGeForce RTX 4070 Ti
- Core Clock2310 MHz
- Boost Clock2610 MHz
- 12GB GDDR6X memory enables high-resolution textures
- Boost clock of 2610 MHz accelerates frame rates
- 7680 CUDA cores handle parallel compute workloads
- 2 x HDMI 2.1a and 3 x DisplayPort 1.4a drive four displays
- Dual ball fan bearings rated for 20K hours at 105°C extend cooler lifespan
TUF Gaming RTX 4070 Ti 12GB GDDR6X
This ASUS TUF Gaming graphics card uses the NVIDIA GeForce RTX 4070 Ti GPU with 7680 CUDA cores and 12GB of GDDR6X memory on a 192-bit interface. It connects through a PCI Express 4.0 slot and provides two HDMI 2.1a ports plus three DisplayPort 1.4a outputs for up to four displays at 7680 x 4320 resolution. The board requires a 16-pin power connector and a 750W power supply for its 285W thermal design power.
Sustained load behaviour with axial-tech cooling
Axial-tech fans scaled for 21 percent more airflow work with dual ball bearings rated for twice the lifespan of conventional designs. Military-grade capacitors rated for 20K hours at 105C stabilise the GPU power rail during extended sessions. A metal exoskeleton adds structural rigidity and vents that improve heat reliability while the Auto-Extreme automated manufacturing process raises overall consistency.
Upgrade path from RTX 4070 12GB or earlier
The 7680 CUDA cores and 2610 MHz boost clock deliver a measurable step up from the RTX 4070 12GB or earlier Ada Lovelace cards. Fourth-generation Tensor cores and third-generation RT cores accelerate DLSS 3 frame generation and ray tracing workloads respectively. The jump is worth it when 1440p ultra settings or 4K gaming with upscaling demand more shader throughput and memory bandwidth than the base model provides.
Highlights
- 12GB GDDR6X memory enables high-resolution textures
- Boost clock of 2610 MHz accelerates frame rates
- 7680 CUDA cores handle parallel compute workloads
- 2 x HDMI 2.1a and 3 x DisplayPort 1.4a drive four displays
- Dual ball fan bearings rated for 20K hours at 105°C extend cooler lifespan
Specifications
| Brand | ASUS |
|---|---|
| Series | TUF Gaming |
| Model | TUF-RTX4070TI-12G-GAMING |
| Part Number | 90YV0IJ1-M0AA00 |
| Interface | PCI Express 4.0 |
| Chipset Manufacturer | NVIDIA |
| GPU Series | NVIDIA GeForce RTX 40 Series |
| GPU | GeForce RTX 4070 Ti |
| Core Clock | 2310 MHz |
| Boost Clock | 2610 MHz |
| CUDA Cores | 7680 |
| Memory Size | 12GB |
| Memory Interface | 192-Bit |
| Memory Type | GDDR6X |
| DirectX | DirectX 12 |
| OpenGL | OpenGL 4.6 |
| Multi-Monitor Support | 4 |
| HDMI | 2 x HDMI 2.1a |
| DisplayPort | 3 x DisplayPort 1.4a |
| Max Resolution | 7680 x 4320 |
| Cooler | Triple Fans |
| Thermal Design Power | 285W |
| Recommended PSU Wattage | 750W |
| Power Connector | 1 x 16-Pin |
| HDCP Ready | Yes |
| Form Factor | ATX |
| Max GPU Length | 305 mm |
| Slot Width | 3.25 Slot |
| Shipping weight | 1.75 kg |
| Package size | 348 × 262 × 74 mm |
Questions about this item
How loud and hot does the triple-fan cooler run during all-day loads with a 285W TDP?
The Axial-tech fans deliver 21% more airflow and dual ball bearings last twice as long as sleeve designs, while military-grade capacitors rated for 20K hours at 105C keep the power rail stable under sustained 285W loads.
What power supply and connector must my system already have for this 16-Pin card?
A 750W PSU is recommended and the card draws power through a single 16-Pin connector, so your supply must provide that cable or an approved adapter.
Will the 3.25-slot, 305mm length fit alongside my existing ATX motherboard and case?
The card occupies 3.25 slots and measures 305mm long, so verify your case clearance and motherboard spacing before installing it next to other expansion cards.
