Black dual-fan graphics card with silver accents

ASUS

ASUS PRIME Radeon RX 9060 XT 8GB GDDR6 Graphics Card

SKU CH-KXP4-MN3ZD

Delivers 2048 stream processors and 8GB 128-bit GDDR6 over PCI Express 5.0 x16 with HDMI 2.1b and DisplayPort 2.1a outputs

  • InterfacePCI Express 5.0 x16
  • Chipset ManufacturerAMD
  • GPU SeriesAMD Radeon RX 9000 Series
  • GPURadeon RX 9060 XT
  • ArchitectureRDNA 4
  • Stream Processors2048
  • RDNA 4 architecture powers 2048 stream processors
  • 8GB GDDR6 memory runs at 20 Gbps on 128-bit bus
  • PCI Express 5.0 x16 interface enables high bandwidth
  • HDMI 2.1b and dual DisplayPort 2.1a drive three monitors
  • DirectX 12 Ultimate and OpenGL 4.6 support modern graphics features

ASUS PRIME Radeon RX 9060 XT 8GB

The ASUS PRIME Radeon RX 9060 XT 8GB is a graphics card built on the AMD RDNA 4 architecture. It targets gamers and creators who need 8GB of GDDR6 memory on a 128-bit interface. The GPU provides 2048 stream processors and connects via PCI Express 5.0 x16. It supports DirectX 12 Ultimate and OpenGL 4.6 for modern titles and professional workloads.

Thermals noise and power draw

The card uses the PRIME cooling design from ASUS to manage heat during typical gaming sessions. Power draw scales with the 20 Gbps memory clock and 2048 stream processors under load. Fan speed adjusts automatically to balance airflow and acoustic output. The PCI Express 5.0 x16 interface delivers sufficient bandwidth without requiring auxiliary power connectors beyond the standard specification.

Display outputs and software

One HDMI 2.1b port and two DisplayPort 2.1a connectors drive up to three monitors simultaneously. The AMD Adrenalin driver suite enables features such as Radeon Super Resolution and Anti-Lag for supported games. ASUS GPU Tweak III provides a dashboard for clock offsets, fan curves and real-time monitoring. These tools let users tailor performance to specific applications without additional hardware.

Highlights

  • RDNA 4 architecture powers 2048 stream processors
  • 8GB GDDR6 memory runs at 20 Gbps on 128-bit bus
  • PCI Express 5.0 x16 interface enables high bandwidth
  • HDMI 2.1b and dual DisplayPort 2.1a drive three monitors
  • DirectX 12 Ultimate and OpenGL 4.6 support modern graphics features

Specifications

BrandASUS
SeriesPRIME
ModelPRIME-RX9060XT-O8G
Part Number90YV0MI0-M0AA00
InterfacePCI Express 5.0 x16
Chipset ManufacturerAMD
GPU SeriesAMD Radeon RX 9000 Series
GPURadeon RX 9060 XT
ArchitectureRDNA 4
Stream Processors2048
Effective Memory Clock20 Gbps
Memory Size8GB
Memory Interface128-Bit
Memory TypeGDDR6
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support3
HDMI1 x HDMI 2.1b
DisplayPort2 x DisplayPort 2.1a
ColorBlack
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Recommended PSU Wattage550W
Power Connector8-Pin
HDCP ReadyYes
Form FactorATX
Max GPU Length304 mm
Card Dimensions (L x H)304 x 126 x 50mm
Slot Width2.5 Slots
Package Contents1 x Thank you card
1 x Speedsetup Manual

Questions about this item

How do I install the PCI Express 5.0 x16 graphics card, and what step do people often miss?

Insert the card fully into the top PCIe 5.0 x16 slot until the retention latch clicks, then attach the required power cables from the PSU before closing the case. The step most often missed is connecting the auxiliary power connectors, which prevents the card from starting.

What maintenance or replacement will the ASUS PRIME Radeon RX 9060 XT need over time?

Dust the heatsink and fans every few months with compressed air to keep temperatures stable. The thermal paste between the GPU die and cooler may need replacement after several years if temperatures rise noticeably. The 8GB GDDR6 memory and 2048 stream processors are soldered and not user-replaceable.

What limit appears first when the Radeon RX 9060 XT runs at full load for extended periods?

The 128-bit memory interface running at 20 Gbps sets the bandwidth ceiling, so memory-intensive workloads hit throughput limits before the 2048 stream processors saturate. The 8GB GDDR6 capacity can also become a constraint in high-resolution textures or large datasets.
