Green circuit board with silver PCIe connector, two silver heatsinks and LED lights

Astro Gaming

Astro Gaming 2 in 1 Accessory M.2 NVME SATA mSATA Adapter Card with 2 Aluminum Heatsinks

SKU CH-B2M4-RGBR6

Adapter card mounts M.2 NVMe, M.2 SATA and mSATA SSDs with dual aluminium heatsinks and status LEDs

  • Supports NVME Key-M drives in 2230 2242 2260 2280 form factors via PCIe 3.0 x4
  • Works with SATA Key-B/B+M M.2 SSDs 2230 2242 2260 2280 over SATA channel
  • Connects 30x50mm mSATA SSDs through dedicated SATA interface
  • Two aluminum heatsinks plus PCB 24 copper-hole ventilation keep drives cool
  • Regular and low-profile brackets included with LED status indicators no driver needed

Multi-Protocol SSD Adapter

This adapter card installs in a PCIe 3.0 x4 slot and accepts three drive types. Key-M M.2 NVME drives in 2230, 2242, 2260, and 2280 lengths connect at full bus speed. Key-B or B+M M.2 SATA drives in the same lengths use the onboard SATA channel. A 30x50mm mSATA drive also connects through the SATA channel. Two aluminium heatsinks and a PCB with 24 copper ventilation holes provide active cooling. Both full-height and low-profile brackets are included for chassis flexibility.

PCIe 3.0 x4 NVME Path

The single specification that decides fit is the Key-M NVME interface running over PCIe 3.0 x4. Only M.2 drives with a Key-M notch will operate on this high-speed path. Key-B or B+M SATA drives and mSATA drives are limited to the separate SATA channel and will not reach NVME speeds. No driver installation is required for any supported drive type. LED indicators show power and data transfer status for each connection.

Three Drives One Slot

The card handles one NVME drive at PCIe 3.0 x4 bandwidth plus one M.2 SATA or mSATA drive at SATA speeds simultaneously. It runs out when a build requires two NVME drives or more than one SATA device at once. Builders needing RAID arrays or multiple high-speed NVME volumes must add a second adapter or a motherboard with additional native slots. The dual heatsink design manages thermals for sustained transfers on the NVME drive.

Highlights

  • Supports NVME Key-M drives in 2230 2242 2260 2280 form factors via PCIe 3.0 x4
  • Works with SATA Key-B/B+M M.2 SSDs 2230 2242 2260 2280 over SATA channel
  • Connects 30x50mm mSATA SSDs through dedicated SATA interface
  • Two aluminum heatsinks plus PCB 24 copper-hole ventilation keep drives cool
  • Regular and low-profile brackets included with LED status indicators no driver needed

Specifications

No published specifications for this item yet.

Questions about this item

What does the PCIe 3.0 x4 link mean for a Key-M M.2 NVME SSD installed on this adapter?

The adapter connects a Key-M M.2 NVME SSD through a PCIe 3.0 x4 channel, so the drive runs at its native PCIe 3.0 x4 speed instead of being limited by a slower interface.

Which interfaces are used for the M.2 SATA and mSATA slots, and what do they cap at?

Both the M.2 SATA slot for Key-B/B+M drives and the mSATA slot for 30x50mm drives connect through a SATA channel, so each is limited to SATA III throughput.

What brackets and clearances are needed to mount this card in a chassis?

The package includes both a regular-size and a low-profile slot bracket, letting you secure the PCB in standard or slim cases without extra hardware.
