Compact 8-litre barebone chassis in black, stands vertical or horizontal

ASRock

ASRock DESKMEET X300W/B/BB/BOX/US barebone mini PC

SKU CH-VESH-AF4F3 MPN DESKMEET X300W/B/BB/BOX/US

An 8-litre barebone chassis that fits a dual-slot graphics card up to 20 cm long and supports AMD Ryzen AM4 processors up to 65 W

  • CPU TypeSupports AMD Ryzen 2000 / 3000 / 4000 G-Series / 5000 / 5000
  • CPU SocketAMD Socket AM4
  • North BridgeAMD X300
  • Memory installedNo Memory
  • Memory slot4 x 288Pin DIMM
  • Memory Type SupportedAMD Ryzen 5000/4000 series - 3200MHz AMD Ryzen 3000/2000 ser

Support CPU Support AMD 2/3/4/5000 CPU

Support Memory Type DIMM DDR4

  • DIMM DDR5
  • DIMM DDR4
  • SO-DIMM DDR5
  • SO-DIMM DDR4

Struck-through versions exist but are not stocked here.

Support Max Memory 128GB

  • Supports AMD Ryzen 2000 to 5000 G-Series processors up to 65W
  • Accommodates dual-slot graphics cards up to 20cm long
  • Four DDR4 DIMM slots support up to 128GB memory
  • 8-litre chassis fits vertical or horizontal orientation
  • DisplayPort, HDMI and D-Sub video outputs included

Versatile 8-litre barebone

The ASRock DeskMeet X300 is an 8-litre mini-PC barebone that accepts AMD Ryzen AM4 desktop processors up to 65 W. It targets builders who want a compact system for daily computing, gaming, home entertainment or content creation without committing to a proprietary form factor. The chassis can stand vertically or horizontally to suit desk space.

Build integration and expansion

The board provides a PCIe 3.0 x16 slot for a dual-slot graphics card up to 20 cm long, freeing users from integrated graphics limits. Four 288-pin DDR4 DIMM slots support up to 128 GB in dual-channel mode at 3200 MHz with Ryzen 5000 or 4000 G-Series, or 2933 MHz with 3000 and 2000 series. Storage options include two SATA 6.0 Gb/s ports and one Ultra M.2 2280 PCIe Gen3 x4 slot. CPU cooler height is limited to 54 mm.

Bundled connectivity and software impact

Front I/O supplies one USB 3.2 Gen1 Type-C, two USB 3.2 Gen1 Type-A and two USB 2.0 Type-A ports for peripherals. Rear video outputs comprise DisplayPort, HDMI and D-Sub, enabling multi-monitor setups without a discrete card. Onboard Realtek ALC897 audio and RTL8111H 1 Gbps LAN handle sound and wired networking. A key-E 2230 M.2 slot is reserved for a Wi-Fi and Bluetooth module, which is not included.

Highlights

  • Supports AMD Ryzen 2000 to 5000 G-Series processors up to 65W
  • Accommodates dual-slot graphics cards up to 20cm long
  • Four DDR4 DIMM slots support up to 128GB memory
  • 8-litre chassis fits vertical or horizontal orientation
  • DisplayPort, HDMI and D-Sub video outputs included

Specifications

BrandASRock
ModelDESKMEET X300W/B/BB/BOX/US
CPU TypeSupports AMD Ryzen 2000 / 3000 / 4000 G-Series / 5000 / 5000 G-Series Processors
CPU SocketAMD Socket AM4
North BridgeAMD X300
Memory installedNo Memory
Memory slot4 x 288Pin DIMM
Memory Type SupportedAMD Ryzen 5000/4000 series - 3200MHz
AMD Ryzen 3000/2000 series - 2933MHz
Max Memory Supported128GB
Dual Channel Memory SupportedYes
PCI Express 3.0 x161 x PCI Express 3.0 x16
Other1 x M.2 (key E 2230) slot for Wi-Fi + BT Module
Storage InstalledNo Hard Drive
Serial ATA2 x SATA 6.0Gb/s
M.2 Slot1 x Ultra M.2 (2280) PCIe Gen3 x4 slot
SATA RAIDRAID 0, 1
Onboard AudioRealtek ALC897
LANRealtek RTL8111H
Max LAN Speed1Gbps
Front USB1 x USB 3.2 Gen1 Type-C
2 x USB 3.2 Gen1 Type-A
2 x USB 2.0 Type-A
Front Audio Ports1 x Headphone/Headset Jack
VGA1 x D-sub
HDMI1
DisplayPort1 x DisplayPort
Rear USB2 x USB 2.0
2 x USB 3.2 Gen1 Type-A
RJ451
Rear Audio Ports1 x Audio Jack (Line out)
Other Rear PortsConnectors:
1 x Chassis Intrusion Header
1 x CPU Fan Connector (4-pin)
1 x Chassis/Water Pump Fan Connectors (4-pin)
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
1 x Front Panel Header
1 x USB 2.0 Headers (Support 2 USB 2.0 ports) (Supports ESD Protection)
1 x COM Port Header (Optional for X300-ITX/COM model)
Power Supply500W power supply (80+ Bronze, peak 550W)
Dimensions8.59" x 6.61" x 6.61" (excl. Protrusions)
8.72" x 6.61" x 9.30" (incl. Protrusions)
PackagingAccessories:
Quick Installation Guide
2 x SATA Data Cables
1 x Screws Package
1 x Intel AC-3168 Wi-Fi Kit
Shipping weight3.70 kg
Package size325 × 290 × 221 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will a 65 W Ryzen 5000 CPU hit its thermal limit with the 54 mm cooler height restriction?

The chassis only accepts CPU coolers up to 54 mm tall, matching the AMD Wraith Stealth, so a 65 W processor stays within its designed cooling envelope.

How loud and hot does the system get when a dual-slot graphics card runs all day in the 8-litre case?

A dedicated MOSFET heatsink handles VRM heat, while the single PCIe 3.0 x16 slot vents through the side panel, keeping sustained GPU loads manageable in the compact volume.

Which DDR4 DIMMs must I already own to reach 3200 MHz on a Ryzen 5000 G-Series chip?

Four 288-pin DDR4 modules rated for 3200 MHz are required; the board runs Ryzen 3000 or 2000 series at 2933 MHz instead.
