Ashcroft T2 pressure transducer, grey nylon housing, quarter-inch NPT male thread, four-pin M12 connector

Ashcroft

Ashcroft T27M0242EW30#GXCY Pressure Transducer 30 PSI

SKU CH-FPKT-GRJ6F

Measures pressure up to 30 psi with 4 to 20 mA output and ±0.25 % accuracy

  • TypeElectronic
  • 0–30 psi range suits low-pressure monitoring
  • ±0.25 % full-scale accuracy delivers reliable readings
  • 4–20 mA two-wire loop simplifies installation
  • IP66 and NEMA 4X housing resists harsh environments
  • 40 °F to 257 °F operating span handles extreme temperatures

30 PSI Transducer for Industrial Monitoring

The Ashcroft T27M0242EW30#GXCY is a pressure transducer designed for test and measurement tasks. It delivers a 4 to 20mA DC output signal proportional to the applied pressure. The unit operates on a 9 to 36V DC supply using a two-wire loop-powered configuration. Its measuring range spans 0 to 30 PSI with an accuracy of +/- 0.25 percent of full scale.

Check Loop Power and M12 Wiring

Verify that your system provides a DC voltage between 9 and 36 volts to power the transmitter loop. Confirm the controller accepts a 4 to 20mA current signal over a two-wire connection. Ensure the 4-pin M12 connector pinout matches your existing cable assembly. The process connection requires a female 1/4 inch NPT port on the vessel or pipe.

Replaces 1/4 NPT Transmitters in Harsh Areas

This transducer replaces older 1/4 inch NPT pressure transmitters where a rugged NEMA 4X and IP66 rated housing is required. The nylon body withstands ambient temperatures from -40 to 257 degrees Fahrenheit. The upgrade is justified when the application demands the specified +/- 0.25 percent full-scale accuracy and M12 connectivity. It is not suitable for installations requiring a different process thread size or voltage output.

Highlights

  • 0–30 psi range suits low-pressure monitoring
  • ±0.25 % full-scale accuracy delivers reliable readings
  • 4–20 mA two-wire loop simplifies installation
  • IP66 and NEMA 4X housing resists harsh environments
  • 40 °F to 257 °F operating span handles extreme temperatures

Specifications

BrandASHCROFT
TypeElectronic

Questions about this item

What comes in the box with the Ashcroft T27M0242EW30#GXCY transducer, and what must be purchased separately?

The transducer ships as a single unit with a 1/4 in male NPT process connection and a 4-pin M12 electrical connector. A mating M12 cable, a 9 to 36V DC power supply, and any required mounting hardware are not included.

How do I decide between the available pressure ranges for this T2 series model?

This specific model is factory calibrated for a 0 to 30 PSI span with a 4 to 20mA output. Select it when your application's maximum working pressure is at or below 30 PSI; choose a different T2 variant for higher or lower ranges.

What does the ±0.25 % full-scale accuracy mean for the 4 to 20mA signal in a real installation?

At the 30 PSI full scale, the output current can deviate by up to ±0.25 % of span, so the 20 mA reading may represent a pressure slightly above or below the true 30 PSI value.
