Compact cylindrical transducer with DIN connector and 1/8 NPT male thread

Ashcroft

Ashcroft G2 pressure transducer 0-100 psi 1-5V DC

SKU CH-Z82E-QVBRS

Measures 0 to 100 psi with a 1 to 5V DC output and +/- 0.50 percent full-scale accuracy

  • Accurate readings with ±0.50 % full-scale precision
  • Wide 9–36 V DC supply fits many systems
  • Rugged NEMA 4X / IP65 enclosure resists harsh environments
  • Operates from –40 °F to 257 °F for extreme conditions
  • Standard DIN 43650 Form A connector simplifies wiring

Pressure transducer for 0-100 psi systems

The Ashcroft G2 transducer measures pressure from 0 to 100 psi and outputs a 1 to 5V DC signal. It operates on a 9 to 36V DC supply with a 3-wire connection. The unit is rated NEMA 4X and IP65 for dust and water protection.

DIN 43650 connector and cable gland entry

The transmitter uses a DIN 43650 Form A connector for electrical attachment. A cable gland provides the wiring entry point. These fittings determine the cable type and sealing method required for installation.

Check process connection and voltage supply

The process connection is a male 1/8 inch NPT thread. Verify that your port matches this size and thread type. Confirm your system provides 9 to 36V DC power and can accept a 1 to 5V DC output signal.

Highlights

  • Accurate readings with ±0.50 % full-scale precision
  • Wide 9–36 V DC supply fits many systems
  • Rugged NEMA 4X / IP65 enclosure resists harsh environments
  • Operates from –40 °F to 257 °F for extreme conditions
  • Standard DIN 43650 Form A connector simplifies wiring

Specifications

BrandASHCROFT

Questions about this item

Will the 1/8 in NPT process connection need periodic resealing or replacement?

The male 1/8 in NPT thread seals with standard pipe tape or sealant; inspect and reapply during routine system maintenance.

What limit appears first when the transducer operates continuously at full scale?

The ±0.50% full-scale accuracy spec is the published performance boundary; sustained pressure at 100 psi stays within that tolerance.

How much heat does the G2 series generate when powered at 36V DC all day?

Power draw at 36V DC is only a few milliamps, so self-heating is negligible; the housing is rated to 257°F maximum operating temperature.
