Stainless steel cylindrical pressure transducer with M12 connector

Ashcroft

Ashcroft G17M0242EW3000# Pressure Transducer 0-3000 psi

SKU CH-F4RV-M0HHH

Pressure transducer measures 0 to 3000 psi with 4 to 20mA output and ±0.50% accuracy

  • Measures 0 to 3000 psi with +/- 0.50% accuracy
  • 4 to 20mA output on 9 to 36V DC power
  • NEMA 4X and IP67 rated for harsh environments
  • Operates from -40 to 257 degrees F
  • 1/4 in male NPT with 4-pin M12 connector

Ashcroft G2 Series 0–3000 psi Transducer

The Ashcroft G2 pressure transducer measures 0 to 3000 psi with a 4–20 mA two-wire output. It connects through a 4-pin M12 plug and a 1/4 in male NPT process port. The unit suits hydraulic, pneumatic and industrial monitoring tasks that demand a compact stainless-steel sensor.

Sustained-load stability and environmental rating

Accuracy holds at ±0.50 % of full scale across the -40 °F to 257 °F operating range. The NEMA 4X and IP67 sealed housing resists wash-down, corrosion and temporary immersion. Power input accepts 9 to 36 V DC, so voltage drops on long cable runs do not shift the signal.

Pre-installation checks for your system

Verify that the 1/4 in male NPT thread matches the port on your manifold or pipe fitting. Confirm the control system reads a 4–20 mA current loop and supplies 9–36 V DC to the transmitter. Ensure the 1/2 in FNPT conduit entry or M12 cable route fits the enclosure layout and that the ambient temperature stays within the rated limits.

Highlights

  • Measures 0 to 3000 psi with +/- 0.50% accuracy
  • 4 to 20mA output on 9 to 36V DC power
  • NEMA 4X and IP67 rated for harsh environments
  • Operates from -40 to 257 degrees F
  • 1/4 in male NPT with 4-pin M12 connector

Specifications

BrandASHCROFT

Questions about this item

Does the G2 transducer generate noticeable heat or draw much power when running continuously at 3000 psi?

The unit operates on 9 to 36V DC with a 4 to 20mA DC output loop, so power draw stays low and self-heating is minimal even during all-day use.

What existing wiring and fittings do I need to install this 4-pin M12 transmitter?

You need a 9 to 36V DC supply, a 2-wire 4 to 20mA input on your controller, a 1/4 in male NPT process port, and a 1/2 in FNPT conduit entry for the M12 cable.

Will this NEMA 4X, IP67 sensor connect directly to my older panel meter that expects a 4 to 20mA signal?

Yes — the transducer provides a standard 4 to 20mA DC output over two wires, compatible with legacy panel meters, PLCs or recorders that accept that signal range.
