Ashcroft
Ashcroft A4SBM0442D05# Intrinsically Safe Transducer 0-5 psi accessory
Intrinsically safe pressure transducer measuring 0 to 5 psi with 4 to 20 mA output and DIN 43650 connector
- Intrinsically safe design for hazardous-area pressure monitoring
- 0 to 5 psi range with ±0.50 % full-scale accuracy
- 4–20 mA two-wire loop output simplifies wiring
- NEMA 4X and IP65 enclosure resists wash-down and dust
- Operates from -40 °F to 257 °F on 12–30 V DC
Intrinsically Safe Transducer 0-5 psi
The Ashcroft A4 series transducer measures pressure from 0 to 5 psi with a 4 to 20mA DC output. It is built for hazardous-area installations where intrinsic safety certification is required. The DIN 43650 Form A connector simplifies wiring in the field.
Accuracy and operating envelope
Accuracy is rated at +/- 0.50 percent of full scale across the range. The unit operates from -40 to 257 degrees Fahrenheit and accepts a 12 to 30V DC supply. NEMA 4X and IP65 ratings protect against wash-down and dust ingress.
1/2 inch NPT process connection
A male 1/2 inch NPT thread mounts directly into compatible process ports without adapters. The two-wire loop-powered design reduces cabling cost and panel space. Mating connector is included for immediate termination.
Highlights
- Intrinsically safe design for hazardous-area pressure monitoring
- 0 to 5 psi range with ±0.50 % full-scale accuracy
- 4–20 mA two-wire loop output simplifies wiring
- NEMA 4X and IP65 enclosure resists wash-down and dust
- Operates from -40 °F to 257 °F on 12–30 V DC
Specifications
| Brand | ASHCROFT |
|---|
Questions about this item
Will the A4 transducer's 1/2 in male NPT process connection thread directly onto my existing pressure washer pump outlet?
The transducer has a 1/2 in male NPT process connection, so it will thread directly onto a matching female NPT port; verify your pump outlet uses the same thread standard before installing.
How can I confirm the transducer is operating correctly after wiring it to a 12 to 30V DC supply?
With power applied and zero pressure, the output should read 4 mA; at full-scale 5 psi it should read 20 mA, staying within the stated +/- 0.50 % accuracy across the range.
Does the box include the mating DIN 43650 Form A connector, or must I source it separately?
The specification lists wiring entry with mating connection, indicating the matching DIN 43650 Form A connector is supplied in the box.
