Ashcroft digital vacuum gauge with transmitter, stainless steel body, IP65 rated, bottom 1/4 NPT connection

Ashcroft

Ashcroft 302174SD02LXBLBKVAC/60 Digital Vacuum Gauge with Transmitter

SKU CH-TSRS-SG3GP

Digital vacuum gauge with 4–20 mA transmitter, ±0.25 % accuracy, IP65 rating, and multiple display units

  • TypeElectronic
  • +/- 0.25 % full-scale accuracy for reliable readings
  • 4-20 mA DC output enables remote monitoring
  • IP65 rated enclosure resists dust and water ingress
  • Stainless steel wetted parts suit harsh media
  • Vacuum to 60 psi range covers diverse applications

Ashcroft 302174SD02LXBLBKVAC/60 Digital Vacuum Gauge

The Ashcroft 302174SD02LXBLBKVAC/60 is a new digital vacuum gauge with an integrated transmitter. It features a nominal dial size of 3 inches and wetted parts made from stainless steel. The instrument delivers an accuracy of +/- 0.25 percent of full scale across its operating range.

Suitable Applications and Limitations

This gauge suits technicians who need a 4 to 20mA DC output signal for remote monitoring or control systems. It also fits installations requiring an IP65 rated enclosure with a bottom mounted 1/4 inch male NPT process connection. Buyers who require a gauge without a transmitter output or who need a different process connection type should look at alternative models.

Critical Specification Transmitter Output

The defining specification is the 4 to 20mA DC transmitter output which enables integration with data acquisition and control systems. This output operates across the full pressure range from -14.5 psi up to 60 psi. Select this model only when a current loop signal is required for the application.

Highlights

  • +/- 0.25 % full-scale accuracy for reliable readings
  • 4-20 mA DC output enables remote monitoring
  • IP65 rated enclosure resists dust and water ingress
  • Stainless steel wetted parts suit harsh media
  • Vacuum to 60 psi range covers diverse applications

Specifications

BrandASHCROFT
TypeElectronic

Questions about this item

What comes in the box with the Ashcroft 302174SD02LXBLBKVAC/60 and what must I buy separately?

The gauge ships as a complete unit with a 4 to 20 mA DC transmitter built in. No sensor or cable is included; you will need a compatible power supply and signal wiring for the current loop.

Which pressure range version should I choose for vacuum work?

The -14.5 to 60 psi span covers full vacuum through low positive pressure in a single instrument, so no separate vacuum-only model is required.

What does the ±0.25 % full-scale accuracy mean when the gauge is installed on a 60 psi system?

Accuracy is ±0.25 % of the 60 psi span, so readings stay within the stated tolerance across the entire -14.5 to 60 psi range.
