Apollo
Apollo 70LF14301 1/2" FNPT Bronze Ball Valve
1/2-inch bronze ball valve rated for 600 psi water and 150 psi steam with chrome-plated brass ball
- TypeOther
- Bronze body resists corrosion for long service life
- Two-piece construction simplifies inline maintenance and inspection
- 600 psi operating pressure handles demanding water and steam systems
- 150 psi steam rating supports heating and process applications
- Chrome-plated brass ball ensures smooth operation and reliable sealing
Bronze Ball Valve for Steam and Water Lines
The Apollo 70LF14301 is a manual two-way ball valve built with a bronze body and chrome-plated brass ball. It is designed for inline installation on 1/2 inch FNPT connections handling steam, water, and vacuum service up to 29 in Hg.
Straight Two-Piece Construction for Inline Builds
The straight, two-piece body style fits directly into piping runs without requiring special offsets or adapters. Its standard port design allows flow while the non-locking handle provides simple quarter-turn operation for isolation or throttling duties.
Pressure Ratings Define the Operating Window
The valve withstands 600 psi maximum operating pressure and 150 psi for steam applications. Combustible gas service is not rated, and 3-A sanitary compliance is not applicable, so specifiers must verify suitability against local codes and the Prop 65 chemical warning.
Highlights
- Bronze body resists corrosion for long service life
- Two-piece construction simplifies inline maintenance and inspection
- 600 psi operating pressure handles demanding water and steam systems
- 150 psi steam rating supports heating and process applications
- Chrome-plated brass ball ensures smooth operation and reliable sealing
Specifications
| Brand | APOLLO |
|---|---|
| Type | Other |
Questions about this item
What is the highest continuous water pressure the 1/2" bronze ball valve can handle?
The valve is rated for a maximum operating pressure of 600 psi for water service.
How hot does the valve body get when passing steam at its rated limit?
Steam service is rated to 150 psi; the bronze body will reach the corresponding saturation temperature for that pressure.
Which pipe thread does the valve connect to without extra adapters?
It has 1/2 inch FNPT ends, so it threads directly onto matching male NPT pipe.
