Bronze Y strainer with stainless steel screen, FNPT connections

Apollo

Apollo 59LF009P2 Y Strainer 2-1/2" FNPT Lead Free Bronze

SKU CH-BANF-7G0JR

Lead-free bronze Y-strainer with 304 stainless steel screen rated for 400 psi at 150 °F

  • Lead-free bronze housing meets potable-water safety standards
  • 400 psi CWP rating handles demanding supply-line pressure
  • 304 stainless-steel screen with 840-micron mesh traps debris effectively
  • 353 °F maximum temperature suits hot-water and steam service
  • 1-1/4 in blow-off port allows quick screen cleaning

2-1/2" FNPT Y Strainer

This 2-1/2 inch FNPT Y strainer filters debris from water lines in residential and commercial plumbing systems. The lead-free bronze body meets potable-water requirements and carries a Class 400 CWP / 125 SWP rating. It installs inline between pipe sections to protect downstream valves, meters and equipment from particulate damage.

Straightforward inline installation

The strainer threads directly onto 2-1/2 inch NPT pipe ends using standard pipe sealant or tape. The included 304 stainless-steel screen with 0.0469 inch perforations and 840 micron rating lifts out through the top cover for cleaning without removing the body. The 1-1/4 inch blow-off port allows flushing while the system remains pressurised.

400 psi at 100 °F with 353 °F maximum

Rated for 400 psi working pressure at 100 degrees Fahrenheit and up to 353 degrees Fahrenheit maximum temperature, it handles typical hot and cold water service. Pressure capacity decreases at elevated temperatures so designers must verify conditions against the class rating. The screen mesh limits flow restriction but will not stop dissolved minerals or very fine silt.

Highlights

  • Lead-free bronze housing meets potable-water safety standards
  • 400 psi CWP rating handles demanding supply-line pressure
  • 304 stainless-steel screen with 840-micron mesh traps debris effectively
  • 353 °F maximum temperature suits hot-water and steam service
  • 1-1/4 in blow-off port allows quick screen cleaning

Specifications

BrandAPOLLO

Questions about this item

How can I confirm the Y strainer is filtering correctly once installed?

Check that system pressure holds at or below 400 psi and that flow remains steady without debris bypassing the 840 micron screen.

What components are included and what must be sourced separately?

The strainer body and 304 stainless steel screen are included; pipe sealant and any required NPT fittings for the 2-1/2 inch ports are not.

Which pressure class should I select for a 150 degree F water line?

Choose the Class 400 CWP-125 SWP version rated for 400 psi at 100 degrees F and 125 psi steam working pressure at 353 degrees F.
