Apollo
Apollo 36LF20401PR Water Pressure Reducing Valve 3/4 In
A 3/4 inch press-connection valve that lowers incoming water pressure to an adjustable 25 to 75 psi range and is certified to NSF/ANSI 61 and ASSE 1003 standards
- TypeOther
- Low-lead bronze construction meets NSF/ANSI 61 safe-drinking-water standards
- Adjustable 25 to 75 psi range lets you set pressure at 50 psi
- Press connection on 3/4 in. inlet/outlet speeds installation without soldering
- Rated for 250 psi working pressure and 180 °F maximum temperature
- Certified to ASSE 1003-2009 and CSA B356 for code compliance
Apollo 36LF20401PR Pressure Reducing Valve
The Apollo 36LF20401PR is a water pressure reducing valve built from low-lead bronze with 3/4-inch press connections. It is designed for plumbing installers who need to lower incoming supply pressure to a safe, adjustable range for residential or light-commercial systems. The valve meets NSF/ANSI 61, ASSE 1003-2009 and CSA B356 standards for potable-water use.
Sustained Pressure Control
The valve maintains a factory setting of 50 psi and can be adjusted between 25 and 75 psi while handling a maximum working pressure of 250 psi. Low-lead bronze construction and a maximum temperature rating of 180 degrees Fahrenheit allow continuous operation under normal hot-water conditions without degradation. Compliance with ARRA and the listed certifications confirms suitability for code-approved installations.
3/4-Inch Press Connection Limits
The 3/4-inch press ends restrict the valve to piping systems that accept that specific connection method and diameter. Installers must verify that the surrounding pipework and press tools match the 3/4-inch specification, as no adapter or alternative fitting is included. The 25-to-75-psi adjustment range also defines the practical limits for downstream pressure requirements.
Highlights
- Low-lead bronze construction meets NSF/ANSI 61 safe-drinking-water standards
- Adjustable 25 to 75 psi range lets you set pressure at 50 psi
- Press connection on 3/4 in. inlet/outlet speeds installation without soldering
- Rated for 250 psi working pressure and 180 °F maximum temperature
- Certified to ASSE 1003-2009 and CSA B356 for code compliance
Specifications
| Brand | APOLLO |
|---|---|
| Type | Other |
Questions about this item
Does the Apollo 36LF20401PR valve make noise or get hot when regulating pressure continuously?
The valve is a passive mechanical device with no moving electrical parts, so it produces no operational noise and generates no heat beyond the water temperature, which is rated up to 180 degrees Fahrenheit.
What pipe fittings or tools are required to install this 3/4 inch press-connection valve?
Installation requires compatible 3/4 inch press fittings and a calibrated press tool; no threading, soldering or additional adapters are needed for the press connection.
Will this valve work correctly on an older plumbing system that runs above 250 psi supply pressure?
The maximum working pressure is 250 psi, so systems exceeding that limit would need an upstream relief device before this valve can operate within its rated range.
