Black USB 2.0 Mini male-to-female panel-mount cable with screw-hole flanges and M3 nuts

Aomoproing

Aomoproing Mini USB 2.0 male-female extension cable screw-hole panel mount 0.3-0.5 m

SKU CH-8A2W-HXWK4

A panel-mount Mini USB 2.0 male-to-female extension cable with screw-hole ears, 28 mm spacing, built-in M3 nuts, foil-and-braid shielding and 0.3–0.5 m length options

Cable Length 0.3 m

  • Screw-hole ears secure the cable to a panel
  • 28 mm hole spacing fits standard M3 mounting hardware
  • Built-in M3 nuts and supplied screws simplify installation
  • Aluminium-foil shield plus 48-strand braid cuts signal loss
  • 0 USB spec with all-copper cores keeps data intact

Panel-mount MINI USB 2.0 extension

This MINI USB 2.0 male-to-female extension cable is designed for panel mounting in equipment chassis. Two screw holes spaced 28 mm apart accept the included M3 nuts and screws for a secure fit. The 0.3 to 0.5 m length suits internal or front-panel routing. It serves installers who need a fixed, shielded connection point.

Shielded cable for tight builds

The cable uses 28 AWG bare copper conductors with aluminium foil and a 48 braid shield to reduce signal attenuation. An HDPE inner insulator and black PVC outer jacket keep the assembly flexible for confined spaces. No extra brackets or adhesives are required because the eared flange locks directly to the panel. Builders who need a removable or longer run cannot use this fixed-length version.

Stable signal under continuous use

High-fidelity transmission is maintained during sustained data transfer thanks to the shielded construction and quality copper core. The screw-lock panel mount prevents vibration from loosening the connection over time. Signal degradation stays low even when the link is active for long periods. Users who require hot-plug cycles without panel removal will find the fixed flange limiting.

Highlights

  • Screw-hole ears secure the cable to a panel
  • 28 mm hole spacing fits standard M3 mounting hardware
  • Built-in M3 nuts and supplied screws simplify installation
  • Aluminium-foil shield plus 48-strand braid cuts signal loss
  • 0 USB spec with all-copper cores keeps data intact

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How far can the signal travel before it degrades at USB 2.0 speeds?

The cable is offered in 0.3 to 0.5 m lengths and uses 28 AWG copper conductors with aluminum foil and 48-strand braid to minimise attenuation.

Does the cable get warm or draw extra power during continuous data transfer?

As a passive USB 2.0 extension with all-copper cores and HDPE insulation, it adds no active circuitry and therefore generates no measurable heat.

What mounting hardware must I already have to secure the panel-mount end?

The female connector has built-in M3 nuts spaced 28 mm apart; the package includes matching fixing screws, so only a panel with two 28 mm-spaced holes is required.
