Anvil 10 inch cast iron blind flange plain finish 16 inch diameter 12 bolt holes

Anvil

Anvil 10 in Blind Flange Class 125 Cast Iron

SKU CH-VS4E-CCFY0

A 10 inch cast iron blind flange rated Class 125 with 12 bolt holes and 175 psi maximum pressure

  • 10 in nominal pipe size fits standard piping systems
  • Cast iron construction rated to 175 psi maximum operating pressure
  • Class 125 flange drilled with 12 bolt holes for secure mounting
  • Operates from -20 to 150 degrees F across varied conditions
  • 16 in outside diameter provides broad sealing surface

10-Inch Class 125 Blind Flange

This Anvil cast-iron blind flange is designed to close a 10-inch nominal pipe run in flat-faced, Class 125 flanged systems. It arrives new, faced and drilled with twelve bolt holes for direct installation.

Installers closing a 10-inch line

Suits maintenance crews and contractors who need a permanent or test-end closure on a 10-inch flat-face pipeline rated to 175 psi. Not suited for systems that require a raised-face gasket surface, a different pressure class, or a flange that allows flow through the centre.

175 psi at up to 150 °F

Comfortably handles water, oil or air service within the -20 °F to 150 °F range at the full 175 psi rating. Headroom ends beyond that temperature ceiling or in applications demanding a higher class rating or a larger nominal size.

Highlights

  • 10 in nominal pipe size fits standard piping systems
  • Cast iron construction rated to 175 psi maximum operating pressure
  • Class 125 flange drilled with 12 bolt holes for secure mounting
  • Operates from -20 to 150 degrees F across varied conditions
  • 16 in outside diameter provides broad sealing surface

Specifications

BrandANVIL

Questions about this item

What size bolts and how many do I need to mount the 10 in blind flange?

The flange has 12 bolt holes; bolt diameter and circle diameter are not applicable for this Class 125 cast iron facing, so match bolts to the mating flange pattern.

Will the 175 psi cast iron flange handle the same pressure as my existing steel piping?

It is rated to 175 psi maximum operating pressure from -20 to 150 degrees F, so it will hold if your steel system stays within those limits.

How can I confirm the 10 in flange is seated correctly after installation?

Verify the 16 in outside diameter sits flat, all 12 bolts are evenly torqued, and a pressure test up to 175 psi shows no leaks at the gasket face.
