Anvil malleable iron trap tee with female NPT threads

Anvil

Anvil 0310517008 Trap Tee 2" FNPT Class 300 Malleable Iron

SKU CH-052H-C2FJC MPN 0310517008

A 2-inch FNPT malleable iron tee rated Class 300 for 1500 psi WOG and 300 psi steam service

  • TypeDrain Components
  • MaterialHAWA
  • 2" FNPT connections fit standard piping
  • Class 300 malleable iron handles 1500 psi WOG
  • UL Listed FM Approved AAR Approved
  • Meets ASME B16.3 for code compliance
  • 5-1/4" length suits compact installations

Anvil 2" Class 300 Malleable Iron Trap Tee

The Anvil 0310517008 is a 2-inch FNPT trap tee constructed from malleable iron for Class 300 service. It provides a robust branch connection in drainage and trap assemblies where threaded joints are required.

Replacing lower-class or damaged threaded tees

This tee upgrades installations that previously used Class 150 fittings or components showing corrosion or thread wear. The jump is justified when system pressure or code compliance demands the higher 1500 psi WOG rating at 150°F and 300 psi saturated steam capacity.

Integrates with 2" NPT piping and approved standards

The fitting mates with standard 2-inch NPT male threads and requires compatible pipe dope or tape for sealing. Its UL Listed, FM Approved, and AAR Approved status under ASME B16.3 frees the installer from sourcing separate certified components for regulated piping systems.

Highlights

  • 2" FNPT connections fit standard piping
  • Class 300 malleable iron handles 1500 psi WOG
  • UL Listed FM Approved AAR Approved
  • Meets ASME B16.3 for code compliance
  • 5-1/4" length suits compact installations

Specifications

TypeDrain Components
MaterialHAWA
BrandAnvil
Model0310517008

Questions about this item

What pipe size and thread type does the 2-inch FNPT trap tee require for connection?

The tee accepts 2-inch NPT male threads on all three ports for direct pipe engagement.

Which sealing method is correct when installing the malleable iron tee to prevent leaks?

Apply PTFE tape or pipe dope to the male threads only; over-tightening female ports can crack the iron casting.

How often should the Class 300 tee be inspected for corrosion or thread wear in a steam system?

Inspect annually for rust, scale buildup, or thread deformation, especially near the 300 psi saturated steam rating limit.
