Small square USB camera module, 32 by 32 millimetres, with IR cut filter and IR LEDs

ALSEYE

ALSEYE USB Camera Module 2.0MP IR Cut 1080P 32x32mm

SKU CH-2RCG-E9H6P

A 2.0MP USB camera module with IR cut and IR LED delivers 1080P at 30fps and 720P at 60fps in a 32x32mm board

  • 1080P resolution at 30 fps for clear Full HD video
  • 60 fps at 720P and 120 fps at 480P for smooth motion capture
  • IR cut filter plus IR LED for day-and-night surveillance
  • USB 2.0 UVC interface works with Windows, Linux, macOS and Android
  • Compact 32 x 32 mm board fits tight industrial or embedded spaces

Compact USB camera for embedded surveillance

The ALSEYE 2.0MP module measures 32x32mm and connects through a USB 2.0 interface, delivering 1080P resolution at 30fps in MJPEG format. An integrated IR cut filter and IR LED board enable continuous day and night operation, including completely dark environments. UVC compliance allows driver-free use on Windows, Linux, macOS and Android 4.0 or above. The board draws 150mA at 5V and operates from -20 to 70 degrees Celsius.

USB 2.0 bandwidth caps frame rates at higher

At the native 1920x1080 resolution the sensor manages 30fps in MJPEG but only 6fps in YUY2, while 1280x720 reaches 60fps in MJPEG and 9fps in YUY2. The highest frame rate, 120fps, is available only at 640x480 in MJPEG, with YUY2 limited to 30fps at that size. Builders needing sustained 60fps at 1080P or uncompressed 4:2:2 at full HD will find the USB 2.0 link a hard bottleneck.

Replaces larger webcams

The 32x32mm footprint fits inside small appliances, vehicle housings or custom rigs where a standard USB webcam or a separate DVR-plus-camera chain would not. The jump is worthwhile when a single-board computer or industrial PC already provides a USB port and the application tolerates the MJPEG/YUY2 frame-rate limits imposed by the 2.0 interface. Buyers who need 4K output, global shutter or frame rates above 120fps at any resolution should look elsewhere.

Highlights

  • 1080P resolution at 30 fps for clear Full HD video
  • 60 fps at 720P and 120 fps at 480P for smooth motion capture
  • IR cut filter plus IR LED for day-and-night surveillance
  • USB 2.0 UVC interface works with Windows, Linux, macOS and Android
  • Compact 32 x 32 mm board fits tight industrial or embedded spaces

Specifications

No published specifications for this item yet.

Questions about this item

Should I pick the MJPEG or YUY2 format for 1080p recording?

MJPEG delivers 30 fps at 1920×1080 while YUY2 drops to 6 fps at the same resolution, so MJPEG is the practical choice for full HD video.

What frame rate will I actually see at 1080p on a USB 2.0 port?

The module streams 1920×1080 at 30 fps in MJPEG mode over USB 2.0 high speed, matching the listed headline figure.

Does the USB 2.0 interface limit the 120 fps claim at 640×480?

No — 640×480 at 120 fps MJPEG fits within USB 2.0 high-speed bandwidth, so the stated rate is achievable.
