Green printed circuit board with black components and a small Bluetooth dongle attached

Alphacool

Alphacool 2 in 1 accessory 24V 100A

SKU CH-ZXPH-G0VPW

A 24 V, 100 A LiFePO4 battery management system with Bluetooth monitoring, parallel-pack support and comprehensive protection

  • Comprehensive protection extends battery life with low/high voltage, short-circuit and temperature safeguards
  • Real-time Bluetooth monitoring tracks SOC, voltage and current for safer operation
  • Scales to 8-plus parallel packs for increased capacity and longer runtime
  • Dual UART, touch display and activation-free Bluetooth simplify integration
  • ISO, FCC, RoHS, PSE and CE certifications confirm safety and compliance

24 V 100 A Battery Management Board

This board protects an 8-series lithium iron phosphate pack rated at 24 volts and 100 amps. It is built for mobility scooters, electric wheelchairs and similar 24 V drive systems that need integrated safety monitoring.

Simple wiring with included harness

The package supplies the BMS, a B-P output lead, a Bluetooth dongle, a sampling cable and a temperature sensor. All connections use the provided loom so no custom cables are required. The Bluetooth module pairs without an activation step; open the app and the board wakes up. Builders unfamiliar with cell-level wiring should follow the manual closely to avoid mis-wiring the sense leads.

Scales to eight parallel packs

The on-board parallel circuit lets you link eight or more identical packs for higher capacity and longer run-time. At 100 amps continuous the single board handles typical scooter and wheelchair loads, but very high peak draws or larger multi-motor setups will exceed its rating.

Highlights

  • Comprehensive protection extends battery life with low/high voltage, short-circuit and temperature safeguards
  • Real-time Bluetooth monitoring tracks SOC, voltage and current for safer operation
  • Scales to 8-plus parallel packs for increased capacity and longer runtime
  • Dual UART, touch display and activation-free Bluetooth simplify integration
  • ISO, FCC, RoHS, PSE and CE certifications confirm safety and compliance

Specifications

No published specifications for this item yet.

Questions about this item

How can I confirm the BMS is protecting the 8S 24V pack correctly after installation?

Pair the Bluetooth dongle with the app to view live SOC, voltage, current and temperature readings; the app will show protection status and send alerts if low voltage, high voltage, short circuit or over-temperature limits are reached.

What comes in the box and what must I source separately for a working 100A system?

Included are the 8S 24V 100A Smart BMS, B-P output line, BT dongle, sampling cable, NTC sensor and manual; you must supply the LiFePO4 cells, main power cables and any mounting hardware.

Which version of this BMS should I choose for an 8-series 24V 100A LiFePO4 build?

This single model is an 8S 24V 100A unit with Bluetooth, dual UART, touch-display support and parallel capability for up to 8 packs; select it when your pack matches those exact voltage and current ratings.
