Compact silver metal box with six BNC outputs and LED indicator

Aja Video Systems

AJA 1x6 12G-SDI Reclocking Distribution Amplifier

SKU CH-3F5H-A6Z8N

A miniature 1x6 12G-SDI re-clocking distribution amplifier with six separately buffered outputs, automatic input detection, and cable equalization up to 90 metres at 12 Gbps

  • Supports 12 Gbps 4K workflows over single link
  • Six separately buffered outputs deliver identical recovered signals
  • Automatic input detection handles 12G through SD-SDI formats
  • Cable equalization reaches 90 m at 12 Gbps on 1694 coax
  • Compact throw-down design includes locking universal power supply

Compact 12G-SDI Distribution

The AJA 1x6 12G-SDI Reclocking Distribution Amplifier is a miniature device built for professional video facilities. It takes a single SDI input and provides six separately buffered outputs identical to the recovered signal. This unit suits engineers who need to split 12G-SDI for 4K/Ultra HD single-link workflows without adding latency.

Build and Connectors

The throw-down package fits behind a monitor, in a rack rear or on a camera rig. A locking power connector prevents accidental disconnection and a universal power supply with international plugs is included. An optional P-TAP cable allows battery power for remote locations. An LED indicator shows signal presence for quick on-site verification.

Cable Reach Limits

Automatic input detection handles 12G, 6G, 3G, HD and SD-SDI formats with re-clocking and equalization on 1694 coax. Maximum distances are 90m at 12 Gbps, 125m at 6 Gbps, 160m at 3 Gbps, 200m at 1.5 Gbps and 470m at 270 Mbps. The unit passes all ancillary data but cannot extend cable runs beyond these physical limits.

Highlights

  • Supports 12 Gbps 4K workflows over single link
  • Six separately buffered outputs deliver identical recovered signals
  • Automatic input detection handles 12G through SD-SDI formats
  • Cable equalization reaches 90 m at 12 Gbps on 1694 coax
  • Compact throw-down design includes locking universal power supply

Specifications

No published specifications for this item yet.

Questions about this item

What maximum cable length does the 12G-SDI interface support at 12 Gbps?

The 12G-SDI interface supports up to 90 metres of 1694 coax at 12 Gbps, with automatic re-clocking and equalisation for each of the six buffered outputs.

What physical mounting options does the miniature enclosure provide?

The compact throw-down package fits behind a monitor, in a rack rear, or on a camera rig, and uses a locking power connector that cannot pull loose.

How is the universal power supply connected, and what common mistake should be avoided?

Plug the included DWP-U-R1 universal supply into the locking DC jack and seat the international plug adapter fully; the step often missed is clicking the lock collar so the connector cannot disconnect during a shoot.
