Small black SFP transceiver module with LC duplex port and gold edge connector

AddOn

AddOn MGBSX1-AO SFP transceiver 1000Base-SX 850nm 550m LC

SKU CH-2Z3C-K55CW MPN MGBSX1-AO

An SFP transceiver delivering 1 Gbps over multi-mode fibre up to 550 m at 850 nm with an LC connector

  • Device TypeOther
  • ProtocolsTCP/IP
  • Ports1 x LC 1000Base-SX Network
  • Max Distance850NM 550M
  • Transfer Rate1 Gbps
  • FeatureGIGABIT ENET SX SFP F/CISCO Operating data rate up to 1.25Gb
  • Linksys MGBSX1 compatible for drop-in deployment
  • 25 Gbps data rate for gigabit throughput
  • 850 nm VCSEL laser for multi-mode fiber
  • Up to 550 m reach on 50/125 µm fiber
  • Hot-pluggable SFP with duplex LC connector

1000Base-SX SFP Transceiver

The AddOn MGBSX1-AO is a small form-factor pluggable transceiver built for 1-Gigabit Ethernet links over multi-mode fiber. It targets network engineers who need a hot-pluggable module that initialises identically to OEM equivalents in switches and routers.

LC Duplex Multi-Mode Interface

The module presents a duplex LC connector and an 850nm VCSEL laser rated for 550m over 50/125µm fiber. That reach and connector combination is the single specification that determines whether the part fits the intended link.

3.3V Operation With Low Heat

The transceiver draws power from a 3.3V supply and uses a TTL logic interface, keeping heat output minimal in normal rack use. No fan or heatsink is required, so the module adds negligible acoustic noise to the chassis.

Highlights

  • Linksys MGBSX1 compatible for drop-in deployment
  • 25 Gbps data rate for gigabit throughput
  • 850 nm VCSEL laser for multi-mode fiber
  • Up to 550 m reach on 50/125 µm fiber
  • Hot-pluggable SFP with duplex LC connector

Specifications

BrandACP
ModelMGBSX1-AO
Device TypeOther
ProtocolsTCP/IP
Ports1 x LC 1000Base-SX Network
Max Distance850NM 550M
Transfer Rate1 Gbps
FeatureGIGABIT ENET SX SFP F/CISCO
Operating data rate up to 1.25Gbps
850nm VCSEL Laser Transmitter
Distance up to 550m with50/125µm SMF
Singer 3.3V Power supply and TTL Logic interface
Duplex LC Connector Interface
Hot Pluggable
Operating Temperature: 0°C ~+ 70°C
Compliant with MSA SFP Specification
Digital diagnostic monitor interface compatible with SFF-8472
Weight20
Package Contents42299T
Shipping weight0.16 kg
Package size121 × 70 × 30 mm

Questions about this item

What does the 1.25 Gbps data rate mean once the transceiver is installed in a switch?

It provides a 1000Base-SX link running at up to 1.25 Gbps over multi-mode fiber, delivering gigabit Ethernet throughput on the connected port.

How does the LC connector interface limit the cable type and reach?

The duplex LC interface requires multi-mode fiber patch cables and supports distances up to 550 m with 50/125 µm fiber at 850 nm.

What does the module need to fit and power up in a chassis?

It uses the standard SFP form factor, a duplex LC port, and a 3.3 V power supply with TTL logic, allowing hot-plug insertion into any compatible SFP cage.
