Small white rectangular PoE splitter with RJ45 and USB-C ports

Adafruit

Adafruit 2.5Gbps PoE Splitter & USB-C 20W PD 2 in 1 accessory

SKU CH-04AP-HPSYW

Splits 2.5 Gbps PoE+ into gigabit data and 20 W USB-C fast charging for tablets and hubs

  • 5 Gbps Ethernet keeps data flowing fast
  • 20 W USB-C PD charges tablets and hubs quickly
  • PoE+ input removes the need for a separate power adapter
  • Passthrough RJ45 port extends the network to another device
  • Compatible with Echo Hub, iPad and other tablets

Single-cable power and data for 2.5 Gbps networks

This adapter splits a PoE+ feed into a 2.5 Gbps Ethernet pass-through port and a USB-C port that delivers up to 20 W of power. It is built for devices such as the Echo Hub, iPad or other tablets that need both wired connectivity and charging from one Cat5e or Cat6 run. The unit requires a PoE switch or injector compliant with IEEE 802.3 at or 802.3 bt to operate.

Replaces separate injectors

If a site already runs 802.3 at PoE+ infrastructure, this splitter removes the need for a local AC outlet and a dedicated USB power supply. The jump is worthwhile when the powered device draws no more than 20 W and the network link can use 2.5 Gbps speeds. On an 802.3 af switch the available budget drops to 15 W, so the connected load must stay below 13 W to avoid overload protection.

Sustained 2.5 Gbps throughput

Under continuous load the Ethernet ports maintain 10/100/1000/2500 Mbps data rates while the USB-C output holds 5 V 3 A, 9 V 2.22 A or 12 V 1.67 A profiles. The splitter draws its own operating power from the PoE+ input, so total consumption at the switch port includes both the attached device and the adapter itself. It is not suited for endpoints that need more than 20 W or for networks limited to 802.3 af power budgets.

Highlights

  • 5 Gbps Ethernet keeps data flowing fast
  • 20 W USB-C PD charges tablets and hubs quickly
  • PoE+ input removes the need for a separate power adapter
  • Passthrough RJ45 port extends the network to another device
  • Compatible with Echo Hub, iPad and other tablets

Specifications

No published specifications for this item yet.

Questions about this item

Does this splitter fit a standard RJ45 Cat5e or Cat6 cable for both the PoE input and the network output?

Yes, both the PoE IN and Network OUT ports are RJ45 and support 10/100/1000/2500 Mbps over Cat5e or Cat6 cabling.

What is the step people miss when hooking up the USB-C PD port for 20 W charging?

The splitter must be powered from an 802.3at or 802.3bt PoE+ source; an 802.3af switch only provides 15 W and will trip its overload protection if the attached device draws more than 13 W.

Will the USB-C PD output need a different charger or cable later if I upgrade to a device that draws more than 20 W?

The splitter’s USB-C port is limited to 20 W (5 V 3 A, 9 V 2.22 A, 12 V 1.67 A), so any device requiring more power will need its own supply.
