Blue fork terminal for 14 AWG wire #10 stud crimp connection

3M

3M M14-10FBX Fork Terminal #10 Stud 14 AWG 600 V Blue

SKU CH-8M60-K14J5

A blue fork terminal for #10 studs accepts 16–14 AWG wire, crimps securely, and is rated 600 V and 347 °F with UL and CSA listings

  • TypeElectrical Connectors
  • Designed for 14 AWG wire with #10 stud fit
  • Tin-plated copper contact ensures low-resistance crimp connection
  • Brazed seam adds mechanical strength to barrel
  • Rated 600 V and 347 °F for demanding circuits
  • UL listed and CSA certified for code compliance

Fork terminal for #10 stud, 14 AWG wire

This 3M M14-10FBX fork terminal accepts 14 AWG wire and fits a #10 stud. It is rated for 600 V and a maximum operating temperature of 347 degrees F. The barrel length is 0.25 in and the overall length is 0.65 in. It suits electrical and industrial wiring tasks.

Brazed seam, tin-plated copper, non-insulated

The brazed seam and tin-plated copper contact provide a secure crimp connection for wire sizes from 16 AWG to 14 AWG. The non-insulated design means no insulation material covers the barrel, leaving the metal exposed. Blue colour coding identifies the wire gauge range. It is UL Listed and CSA Certified.

Handles 14 AWG at 600 V, not for larger gauges

This terminal comfortably handles 14 AWG copper wire at up to 600 V within the stated temperature limit. It runs out at the 14 AWG maximum wire size and cannot accommodate larger conductors. The #10 stud size fixes the mounting hole diameter. It is not for applications requiring insulated barrels or different stud sizes.

Highlights

  • Designed for 14 AWG wire with #10 stud fit
  • Tin-plated copper contact ensures low-resistance crimp connection
  • Brazed seam adds mechanical strength to barrel
  • Rated 600 V and 347 °F for demanding circuits
  • UL listed and CSA certified for code compliance

Specifications

Brand3M
TypeElectrical Connectors

Questions about this item

Will the crimped joint on the 14 AWG wire need periodic re-crimping?

The brazed seam and tin-plated copper barrel create a permanent crimp connection that does not require re-crimping under normal use.

At what current level does the #10 stud connection become the limiting factor?

The terminal is rated for 600 V and wire sizes 16 to 14 AWG; the ampacity limit follows the wire gauge rather than the stud size.

Does the bare copper barrel get hot enough to burn insulation during continuous operation?

Maximum operating temperature is 347 °F, so the barrel can become very hot; keep nearby insulation rated for at least that temperature.
