Five US panel-mount sockets with pre-wired leads, snap-in housing, ETL listed

3 Pins US Power Socket Plug Panel 15A 125V 18AWG

SKU CH-TJH2-YJ492

Panel-mount US power socket with 18 AWG pre-wired leads, 15 A 125 V rating, ETL certified, and snap-on installation

  • Amps15
  • Standards/CertificationsETL
  • Compatibility/FitmentAll devices requiring a standard US power outlet
  • Commercial/ResidentialAll devices requiring a standard US power outlet
  • Snap-on mounting installs in seconds without tools
  • Pre-wired 18 AWG leads cut wiring time and effort
  • 15 A 125 V rating powers household and commercial gear
  • ETL-certified safety meets recognised electrical standards
  • Compact 24 x 24 x 34 mm body fits tight panel cut-outs

Panel-mount outlet for US mains

This 3-pin US power socket plug panel mounts into a 24 x 24 x 34 mm cut-out and is rated at 15 A 125 V. It accepts standard US plugs in residential or commercial equipment. The ETL-listed unit ships in a pack of five, each with an 18 AWG connection line already attached. Builders integrating mains power into enclosures, test rigs or appliances will find it a direct fit.

Snap-on install with pre-wired leads

The snap-on design lets you press the outlet into the panel opening without screws or special tools. Pre-wired 18 AWG leads remove the need to strip and terminate conductors yourself, cutting wiring time and reducing the chance of loose strands. The only common issue is ensuring the panel cut-out matches the 24 x 24 mm footprint; an oversized hole prevents the snap tabs from locking securely.

15 A 125 V AC rating limits

The outlet is certified for 15 A at 125 V AC only; it must not be used on higher-voltage or DC circuits. The 18 AWG leads constrain the continuous current to the plug rating and require protection by a 15 A branch circuit breaker. No grounding terminal beyond the standard third pin is provided, so devices needing a dedicated equipment ground must rely on the plug's ground contact alone.

Highlights

  • Snap-on mounting installs in seconds without tools
  • Pre-wired 18 AWG leads cut wiring time and effort
  • 15 A 125 V rating powers household and commercial gear
  • ETL-certified safety meets recognised electrical standards
  • Compact 24 x 24 x 34 mm body fits tight panel cut-outs

Specifications

Amps15
Standards/CertificationsETL
Compatibility/FitmentAll devices requiring a standard US power outlet
Commercial/ResidentialAll devices requiring a standard US power outlet

Questions about this item

How do I verify the panel is working after mounting it in a 24 x 24 x 34 mm cut-out?

Insert a standard US plug; the pre-wired 18 AWG leads should deliver 125 V at up to 15 A if the ETL-listed outlet is functioning correctly.

What comes in the package and what must I supply myself?

Five snap-on panels with pre-attached 18 AWG connection lines are included; you only need to provide the mounting panel and wire terminations for your circuit.

Which version should I choose for a 15 A 125 V residential or commercial circuit?

The single 15 A 125 V ETL-certified variant with 18 AWG pre-wiring covers both residential and commercial applications requiring a standard US outlet.
